Highly Flexible

5 Degrees of Freedom, High Torque

  • Horizontal Extending Range: 25 in.
  • Vertical Extending Range: 37 in.
  • Gripper Max Opening Angle: 70°
  • Gripper Max Opening Clearance: 5.7 in.
  • Gripper Torque: 33 lbs
  • Degrees of Freedom: 5 DOF
  • Max Load Capacity: 15 lbs

    • Highly Modular

    Modular Design

  • Arm Camera Resolution: 640 x 480
  • Arm Camera Field-of-View: 60 degrees
  • Arm Camera Zoom: 4x
  • Arm Payload Interface: UART (DB9)

    • Robust and Reliable

    The Most Durable Arm That Works in All Weathers

  • Weight: 17.5 lbs
  • Operating Temperature: -10° ~ 160° F
  • Dust and Water Resistance: IP-67 ingress protection rating
  • Explosive Proof: Eexd IIB T4
  • Overload Protection: Yes
  • Service Life: > 20,000 cycles
