Night Vision for Low/No Light Environments

Scene Range (high gain): -13° ~ 212° F

Scene Range (low gain): -40° ~ 1022° F

Field of View: 45° x 35° 2.267 mr

Resolution: 336 x 256

Operating Temperature: -4° ~ 149° F

Humidity: 5% ~ 95% non-condensing

Shock: 200g shock pulse w/ 11 msec sawtooth

Vibration: 4.3g three axis, 8 hr each

Detection for 20+ Gas and Radiation

Sensors: Over 25 intelligent interchangeable field-replaceable sensors including gamma radiation, ppb and ppm PID sensors for VOCs, electrochemical sensors for toxic gases and oxygen, combustible LEL and NDIR sensors, and CO2 NDIR sensor

Sampling: Built-in pump. Average flow rate: 250 cc/min. Auto shutoff in low-flow conditions

Operating Temperature: -4 ° ~ 122 ° F

Humidity: 0% ~ 95% relative humidity (non-condensing)

Dust and Water Resistance: IP-65 ingress protection rating

Safety Certifications (CSA): Class I, Division 1, Groups A, B, C and D, T4; Class II, Division 1, Groups E, F, G T85°C

Safety Certifications (ATEX): 0575 II 1G Ex ia IIC T4 Ga; 2G Ex ia d IIC T4 Gb with IR Sensor installed; I M1 Ex ia I Ma

Safety Certifications (IECEx/ANZEx): Ex ia IIC T4 Ga; Ex ia d IIC T4 Gb with IR Sensor installed; I M1 Ex ia I Ma
